SDS-T150
| Model | Power | LED&MSPSP | Lens | Weight | Dimension () | Packing Size | Installation Tube | Marks | |
| SDS-T50 | 50w | 50Pcs 3030 5S10P | 150*75° | 2.20 | 540*210*70 | 570*220*90 | 60 | Driver room: 180*110*40 |
|
| SDS-T100 | 100W | 2*50Pcs 3030 5S10P | 150*75° | 3.60 | 595*255*75 | 620*280*100 | 60 | Driver room: 220*110*48 |
|
| SDS-T150 | 150w | 3*50Pcs 3030 5S10P | 150*75° | 4.80 | 710*255*75 | 720*270*95 | 60 | Driver room: 220*135*48 |
LED light specification:
| Model | SDST20W | SDST30W | SDST50W SMD | SDST60W SMD | SDST100W SMD | SDST120W | SDST150W |
| Lamp Power | 20W | 30W | 50W | 60W | 100W | 120W | 150W |
| Lamp Flux | 2400LM | 3600LM | 6000LM | 7200LM | 12000LM | 14400LM | 18000LM |
| Product size(mm) | 347*95*65 | 400*130*65 | 540x213x50 | 520x220x70 | 598x255x45 | 550x250x70 | 714x255x50 |
| Material | Die-Alu+Lens | ||||||
| Power Factor | >0.9 | ||||||
| Color Temperature | 3000-3500K; 4000-4500K; 6000-6500K | ||||||
| IP Grade | IP65 | ||||||
| CRI | Ra>70 | ||||||
| Life Time | 50000H | ||||||
| Surger Protector | 4KV-6KV | ||||||
| Input Voltage | AC85-277V | ||||||
| Body Color | Black or Grey | ||||||
| Certificate | BIS, SASO, LVD-EMC, RoHs, IES, TUV, EAC, ISO9001 | ||||||
