LED Street Light SDS2B150



Details

Model Power LED&MSPSP Lens Weight
(kg)
Dimension (mm) Packing Size
(mm)
Installation Tube
BRP371 BRP372 BRP373 top quality outdoor led street lights with 3 years warranty
SDS--2B20
20w 20pcs 3030   7S3P
20pcs 3528.  7S3P
140*90° 0.54 315*128*76 325*78*135
15pcs in
560*410*340
40
SDS--2B30 30w 30pcs 3030 10S3P
30pcs 3528 10S3P
140*90° 0.60 351*142*76 360*150*78
15pcs
047*410*375
40
SDS--2B50 50w
60w
50pcs 3030. 10S6P
50pcs 3528  10S6P
140*90° 0.95 405*166*79 420*365*430 50
SDS--2B120 100w
120w
100pcs 3030 10S10P 140*90° 1.57 484*211*83 525*260*115 60
SDS--2B180 150w
180w
150pcs  3030 10S15P 140*90° 2.15 580*242*83 630*295*115 60
LEDS Luxeon 3030 & Luxeon 5050
Color rendering index NW: 70.   WW: 80
Initial LED luminaire efficacy Up to165 lm/W (depending on the version)
Luminous flux tolerance +-7%
Correlated Color Temperature Warm white (WW): 3000 K          Neutral white (NW): 4000 K   Cool white(CW) :5700K
Lumen maintenance at median useful life* 100000 h min L80   up to L95
Temperature of Working Condition -40-50
Ingress protection code IP66
Driver  Philips Xitanium / Meanwell  ELG HLG XLG upon on request
Mains voltage  AC220-240V 50/60HZ
Power Factor PF≥0.95
Power Tolerance +-11%
Control gear failure rate at median useful life 100000 h 0.1
Surge protection >10kv
Dimming  upon request for 0-10V Dali
Mech. impact protection code IK08




Great Selling Energy Saving E40 60w LED Lamp LED Street Lights
High power waterproof IP65 outdoor aluminum 20W 30W 50W 100W 150W led street lightHigh power waterproof IP65 outdoor aluminum 20W 30W 50W 100W 150W led street light
